F250 4X2 BUS CHASSIS

250hp, Euro 3, Opticruise

  • Wheel Configuration: 4x2
  • Engine: DC09 114 250 hp
  • Emission Class: Euro 3
  • Rear Axle Gear Ratio: 3.42
  • Fuel Tank: 500 dm3 (left)



Technical data

  • Engine type: DC09 114
  • Power at RPM: 250hp/184kW at 1900 RPM
  • Torque at RPM: 1250 NM at 1000-1350 RPM
  • Gearbox type: GR875
  • Gearbox speed: 8-speed + 1 reverse
  • Rear axle gear ratio: 3.42
  • Opticruise: Standard
  • Diff lock: Standard



*all parameters for reference only

  • Total chassis length: 10400 mm
  • Axle distance: 5500 mm
  • Intended bus length (max): 10.5 metre
  • Fuel volume left side: 500 dm3
  • Fuel volume right side: Without
  • Suspension system: Front and rear leaf spring; front and rear anti-roll bar; front and rear heavy duty shock absorbers
  • Hill hold: With
  • Battery: 2 x 140 Ah
  • Alternator: 100A
  • Wheel brake: Drums + EBS
  • Exhaust brake: 187kW at 2400 RPM
  • Steering wheel: Standard adjustable (longitudinal and tilt)
  • Driver seat: Air suspension with tilt adjustments
  • Seat capacity: Maximum 56



*all parameters for reference only

  • Interlock valve parking brake
  • Hill hold
  • Electronic brake control



*all parameters for reference only
