V8 specifications

A complete range

Outstanding uptime and reliability

Keeping your promises and your schedule is an absolute must in the transport industry. With the reliability and speed of a Scania V8, your business is bound to benefit.



The Scania V8 truck range makes a bold and confident statement on the road. This top-of-the-range Scania cab can be equipped to the highest standards for operators who demand the most practical and prestigious vehicle.

Everything you expect

CHOOSE YOUR POWER

With the broadest range on the market, Scania offers almost endless possibilities of finding a powertrain that fits your needs perfectly.

Output Torque Fuel Emission technology Engine PTO
770 Hp 3700 Nm Diesel/HVO Selective catalytic reduction (SCR) 800 Nm
660 Hp 3300 Nm Diesel/HVO Selective catalytic reduction (SCR) 800Nm
650 Hp 3300 Nm Diesel/HVO Selective catalytic reduction (SCR) 800Nm
590 Hp 3050 Nm Biodiesel/Diesel/HVO Selective catalytic reduction (SCR) 800Nm
580 Hp 3000 Nm Biodiesel/Diesel/HVO Selective catalytic reduction (SCR) 800Nm
530 hp 2800 Nm Diesel/HVO Selective catalytic reduction (SCR) 800Nm
520 hp 2700 Nm Diesel/HVO Selective catalytic reduction (SCR) 800Nm

THE SCANIA OPTICRUISE GEARBOX

Scania’s new Opticruise G33CM gearbox, available for the high-out­put 13-litre 500 and 540 hp engines, features improved and speedy gearshifting in combination with better fuel consumption and excellent comfort.



After six years of development and testing, we are introducing a gearbox with plenty of new technologies, such as variable oil volume, improved gear lubrication by oil spray function and a wider gear spread.



Thanks to significantly reduced internal losses, and thereby improved energy efficiency, the G33CM itself offers fuel savings of one percent. The weight has been reduced by 60 kg to be used for increased payload. Additionally, it provides higher uptime with an oil change interval of up to one million km. All this to ensure that your total operating economy is optimised.

The new Scania Opticruise gearbox G33CM is available for all V8 engines up to 660 hp as well as the high-out­put 13-litre 500 and 540 hp engines.

Rear axle gears

Scania’s rear axle range offers a robust and weight optimised design with a wide variety of gears and ratios, so you can find the optimal solution for your operation. All gears are offered with differential locks.

Single driven single reduction

Our gears for single reduction have low complexity and high efficiency and can master gross vehicle and train weights up to 78 tonnes with a wide range of gear ratios from 2.35 up to 5.57.

Single driven hub reduction

The single driven hub reduction axles are offered for the operations where startability, ground clearance and high gross train weights are favourable. They manage gross vehicle and train weights up to 80 tonnes with gear ratios from 3.80 up to 7.18.

TANDEM DRIVEN SINGLE REDUCTION

Tandem driven single reduction is offered for operations where you require traction together with optimal fuel efficiency. The RB662 + R660 tandem gear masters gross vehicle and train weights up to 80 tonnes with gear ratios from 2.92 up to 4.88.

Tandem driven single hub reduction

Our broad tandem driven hub reduction axles are robust and durable and offers great startability and ground clearance. It masters extremely high gross vehicles and train weights to up to 210 tonnes with gear ratios from 3.52 up to 7.63.

Axle configurations

Front, rear, fixed and steered tag axles – Scania can match the requirements of any application. The V8 can be teamed with a wide range of chassis configurations with different heights.

4x2
Chassis height
Extra low, low, normal, high

4x4

Chassis height
High

6x2
Chassis height
Normal

6x2/2
Chassis height
Normal

6x2 pusher

6x2/4

Chassis height
Normal, low
6x2 twin-steer

6x4
Chassis height
Normal, high

6x6
Chassis height
High

4x2
Chassis height
Low, normal, high

4x4
Chassis height
High

6x2
Chassis height
Low, normal

6x2/2
Chassis height
Normal

6x2 pusher

6x2/4

Chassis height
Normal
6x2 twin-steer

6x2*4

Chassis height
Low, normal

6x4
Chassis height
Normal, high

6x6
Chassis height
High

8x2
Chassis height
Normal

8x2*6

Chassis height
Low, normal

8x2 rear-steer

8x2/4

Chassis height
Normal

8x2 twin-steer

8x4

Chassis height
Normal, high

8x4*4

Chassis height
Normal

8x4 rear-stear

10x4*6

Chassis height
Normal

10x4 rear-steer

Contact your dealer

Please contact us if you have any questions about our products, services or other activities within the Scania organisation.

With a wealth of choices and an array of modular configurations, you can tailor your truck to fit your trucking life. Make it a Scania.
